Specifications

• General

  Type

  Compact Excavators

  Operating Weight

  5.85  ton

  12897.04  lb

  Bucket Capacity

  0.25  m³

  0.33  yd³

• Engine

  Emission

  ~TIER 2

  Engine model

  YANMAR 4TNV94L-BVLKC

  YANMAR 4TNV94L-BVLKC

  Rated Power

  36.2  kW / 2,100 rpm

  48.5  hp / 2,100 rpm

  Max. Torque

  -

• Hydraulic System

  Main Pumps Rated Flow

  151  ℓ/min

  151  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  130  ℓ

  34.37  gal

  Hydraulic Tank

  80  ℓ

  21.15  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  11  rpm

  11  rpm

  Travel Speed

  4.2  km/h

  2.61  mph

  Max. Traction Force

  5,302  kgf

  2404.95  lbf

  Max. Gradeability

  30  deg

  30  deg

  Bucket Digging Force (ISO)

  4,079  kgf

  1850.2  lbf

  Arm Digging Force (ISO)

  2,855  kgf

  1295.01  lbf

• Dimensions

  Overall Length

  5,670  mm

  18'7"  ft.in

  Overall Width

  2,000  mm

  6'7"  ft.in

  Overall Height

  2,630  mm

  8'8"  ft.in

  Tail Swing Radius

  1,700  mm

  5'7"  ft.in

  Tumbler Distance

  1,600  mm

  5'3"  ft.in

  Ground Clearance

  332  mm

  1'1"  ft.in

• Operating Range

  Boom Length

  3,000  mm

  9'10"  ft.in

  Arm Length

  1,550  mm

  5'1"  ft.in

  Max. Digging Reach

  5,946  mm

  19'6"  ft.in

  Max. Digging Depth

  3,812  mm

  12'6"  ft.in

  Max. Digging Height

  5,980  mm

  19'7"  ft.in

  Max. Dumping Height

  4,185  mm

  13'9"  ft.in

  Min. Swing Radius

  2,030  mm

  6'8"  ft.in
