Specifications

• General

  Type

  Large Excavators

  Operating Weight

  35.5  ton

  78264.12  lb

  Bucket Capacity

  2.1  m³

  2.75  yd³

• Engine

  Emission

  TIER 2

  Engine model

  HYUNDAI HM8.3

  HYUNDAI HM8.3

  Rated Power

  260  hp / 2,200 rpm

  193.7  kw / 2,200 rpm

  Max. Torque

  117.26  kgf·m / 1,300 rpm

  847.87  lbf.ft / 1,300 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2*315  ℓ/min

  2*315  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  600  ℓ

  158.63  gal

  Hydraulic Tank

  210  ℓ

  55.52  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  11.2  rpm

  11.2  rpm

  Travel Speed

  5  km/h

  3.11  mph

  Max. Traction Force

  32,011  kgf

  14519.94  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  22,661  kgf

  10278.86  lbf

  Arm Digging Force (ISO)

  20,951  kgf

  9503.21  lbf

• Dimensions

  Overall Length

  11,340  mm

  37'2"  ft.in

  Overall Width

  3,190  mm

  10'6"  ft.in

  Overall Height

  3,760  mm

  12'4"  ft.in

  Tail Swing Radius

  3,570  mm

  11'9"  ft.in

  Tumbler Distance

  4,030  mm

  13'3"  ft.in

  Ground Clearance

  1,200  mm

  3'11"  ft.in

• Operating Range

  Boom Length

  6,450  mm

  21'2"  ft.in

  Arm Length

  2,650  mm

  8'8"  ft.in

  Max. Digging Reach

  10,563  mm

  34'8"  ft.in

  Max. Digging Depth

  6,813  mm

  22'4"  ft.in

  Max. Digging Height

  9,869  mm

  32'5"  ft.in

  Max. Dumping Height

  6,852  mm

  22'6"  ft.in

  Min. Swing Radius

  9,310  mm

  30'7"  ft.in
