Excavators
Type
Medium Excavators
Operating Weight
22.4  ton
Emission
TIER 3
Rated Power
151  hp / 1,900 rpm
General
Type
Medium Excavators
Operating Weight
22.4  ton
Bucket Capacity
0.87  m³
Engine
Emission
TIER 3
Engine model
Cummins QSB6.7
Rated Power
151  hp / 1,900 rpm
Max. Torque
63.6  kgf·m / 1,500 rpm
Hydraulic System
Main Pumps Rated Flow
2 X 222  ℓ/min
Implement Circuit
350  kgf/cm²
Tank Capacity
Fuel Tank
310.0  ℓ
Hydraulic Tank
165.0  ℓ
Performance
Swing Speed
12.0  rpm
Travel Speed
5.3  km/h
Max. Traction Force
21,100  kgf
Max. Gradeability
35  deg
Bucket Digging Force (ISO)
15,200  kgf
Arm Digging Force (ISO)
10,900  kgf
Dimensions
Overall Length
9,510  mm
Overall Width
2,600  mm
Overall Height
3,100  mm
Tail Swing Radius
2,800  mm
Tumbler Distance
3,650  mm
Ground Clearance
480  mm
Operating Range
Boom Length
5,650  mm
Arm Length
2,920  mm
Max. Digging Reach
9,960  mm
Max. Digging Depth
6,640  mm
Max. Digging Height
9,740  mm
Max. Dumping Height
6,900  mm
Min. Swing Radius
3,580  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
