Excavators
HX330L
-
Type
Large Excavators
-
Operating Weight
33.5 ton
-
Emission
TIER 4
-
Rated Power
300 hp / 2,200 rpm
- Catalog
Specifications
-
General
Type
Large Excavators
Operating Weight
33.5 ton
Bucket Capacity
1.44 m³
-
Engine
Emission
TIER 4
Engine model
CUMMINS QSL9
Rated Power
300 hp / 2,200 rpm
Max. Torque
145 kgf·m / 1,500 rpm
-
Hydraulic System
Main Pumps Rated Flow
2x277.2 ℓ/min
Implement Circuit
350 kgf/cm²
-
Tank Capacity
Fuel Tank
600 ℓ
Hydraulic Tank
210 ℓ
DEF/ ADBLUE Tank
42.5 ℓ
-
Performance
Swing Speed
9.1 rpm
Travel Speed
5.9 km/h
Max. Traction Force
27,000 kgf
Max. Gradeability
35 deg
Bucket Digging Force (ISO)
23,450 kgf
Arm Digging Force (ISO)
16,290 kgf
-
Dimensions
Overall Length
11,220 mm
Overall Width
3,280 mm
Overall Height
3,380 mm
Tail Swing Radius
3,570 mm
Tumbler Distance
4,030 mm
Ground Clearance
500 mm
-
Operating Range
Boom Length
6,450 mm
Arm Length
3,200 mm
Max. Digging Reach
11,140 mm
Max. Digging Depth
7,370 mm
Max. Digging Height
10,310 mm
Max. Dumping Height
7,240 mm
Min. Swing Radius
4,460 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
