Excavators
Type
Wheel Excavators
Operating Weight
21.18  ton
Emission
STAGE V
Rated Power
173  hp / 2,200 rpm
General
Type
Wheel Excavators
Operating Weight
21.18  ton
Bucket Capacity
1.34  m³0.8~1.34m³
Engine
Emission
STAGE V
Engine model
CUMMINS / B6.7
Rated Power
173  hp / 2,200 rpm
Max. Torque
89.8  kgf·m / 1,300 rpm
Hydraulic System
Main Pumps Rated Flow
2 X 208  ℓ/min
Implement Circuit
350  kgf/cm²
Tank Capacity
Fuel Tank
310  ℓ
Hydraulic Tank
165  ℓ
DEF/ ADBLUE Tank
48  ℓ
Performance
Swing Speed
10.7  rpm
Travel Speed
38.4  km/h
Max. Traction Force
11,713  kgf
Max. Gradeability
35  deg
Bucket Digging Force (ISO)
16,720  kgf
Arm Digging Force (ISO)
11,830  kgf
Dimensions
Overall Length
9,380  mm
Overall Width
2,530  mm
Overall Height
4,020  mm
Tail Swing Radius
2,733  mm
Ground Clearance
353  mm
Operating Range
Boom Length
5,650  mm
Arm Length
2,920  mm
Max. Digging Reach
9,970  mm
Max. Digging Depth
6,430  mm
Max. Digging Height
10,020  mm
Max. Dumping Height
7,160  mm
Min. Swing Radius
3,460  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
